Assessing the yield response to deep ripping near Muradup, Western Australia

2016 - 2018
CC BY 4.0

Research organisaton
Funding source

Trial details

Researcher(s) Joel Andrew (Map IQ)
Jeremy Lemon (DPIRD)
Emma Russell (Southern DIRT)
Simon Zacher (Parahills Farm)
Year(s) 2016 - 2018
Contributor agVivo
Trial location(s) Muradup, WA
Assessing the yield response to deep ripping near Muradup, Western Australia locations
Aims

To assess the impact of deep ripping on crop yield in a gravelly loam soil type near Muradup, WA.

Key messages
  • Deep ripping provided a 260kg/ha yield increase in barley in 2016,
  • Deeper ripping and the use of inclusion plates did not improve barley yield at this site,
Lead research organisation agVivo
Host research organisation N/A
Trial funding source GRDC AVP00003-A
Related program N/A
Acknowledgments

The research undertaken as part of this project is made possible by the significant contributions of the Zacher family who setup the demonstration sites in conjunction with Southern Dirt and Jeremy Lemon from DPIRD. This assessment of the trial and report is an investment by the GRDC

GRDC Project Number: AVP00003-A


Other trial partners Not specified
Download the trial report to view additional trial information

Method

Crop types Cereal (Grain): Barley Oilseed: Canola
Treatment type(s)
  • Management systems: Soil engineering
  • Soil Preparation: Tillage
Trial type
Trial design

Muradup 2016 Barley

Sow date Not specified
Harvest date Not specified
Plot size Not specified
Plot replication Not specified

Muradup 2016 Canola

Sow date Not specified
Harvest date Not specified
Plot size Not specified
Plot replication Not specified

Muradup 2017 Barley

Sow date Unknown
Harvest date Unknown
Plot size Not specified
Plot replication Not specified

Muradup 2017 Canola

Sow date Not specified
Harvest date Not specified
Plot size Not specified
Plot replication Not specified

Muradup 2018 Barley

Sow date Not specified
Harvest date Not specified
Plot size Not specified
Plot replication Not specified

Muradup 2018 Canola

Sow date Not specified
Harvest date Not specified
Plot size Not specified
Plot replication Not specified
Download the trial report to view additional method/treatment information

Download results

Trial results Table 1: Grain Yield x Ripping Method

# Treatment 1
Grain yield (t/ha)
1 Nil 4.1
2 Rip_550mm 4.4
3 Rip_350mm 4.6
4 Rip_350mm+Slot 4.4
5 Heliripper_600mm 3.75
6 OffsetDisk_150mm 4.05
7 Scarifier_250mm 4.4

Trial results Table 2: Grain yield x ripping Method - 2017 Canola

# Treatment 1
Grain yield (t/ha)
1 Nil 1.81
2 Rip_550mm 1.45
3 Rip_350mm 1.62
4 Rip_350mm+Slot 1.52
5 Helirpper_600mm 1.8
6 OffsetDick_150mm 1.17
7 Scarifier 1.2

Grain yield t/ha


Loading

Trial results Table 3: Average Soil Strength

# Treatment 1
Soil loosening depth (cm) Soil strength (kPa)
1 Barrier -5 2500
2 Barrier -10 2500
3 Barrier -15 2500
4 Barrier -20 2500
5 Barrier -25 2500
6 Barrier -30 2500
7 Barrier -35 2500
8 Barrier -40 2500
9 Barrier -45 2500
10 Barrier -50 2500
11 Barrier -55 2500
12 Barrier -60 2500
13 Nil -5 500
14 Nil -10 1500
15 Nil -15 1800
16 Nil -20 2100
17 Nil -25 2200
18 Nil -30 2600
19 Nil -35 2650
20 Nil -40 2600
21 Nil -45 3000
22 Nil -50 3250
23 Nil -55 3500
24 Nil -60 4100
25 Helirpper_60cm -5 200
26 Helirpper_60cm -10 500
27 Helirpper_60cm -15 800
28 Helirpper_60cm -20 900
29 Helirpper_60cm -25 1250
30 Helirpper_60cm -30 1100
31 Helirpper_60cm -35 1100
32 Helirpper_60cm -40 1000
33 Helirpper_60cm -45 1250
34 Helirpper_60cm -50 1100
35 Helirpper_60cm -55 3600
36 Helirpper_60cm -60 5000

Trial results Table 4: Bulk density of soil from each plot was calculated across the trial area.

# Treatment 1
10cm Bulk Density ((g/cm3)) 50cm Bulk Density (g/cm3) 20cm Bulk Density ((g/cm3)) 30cm Bulk density (g/cm3)
1 Control 1.29 1.4 1.41 1.5
2 DAFWA 350mm 1.49 1.51 1.36 1.37
3 DAFWA 350mm + Slotting 1.1 1.72 1.3 1.98
4 DAFWA 550mm 1.13 1.63 1.48 1.78

Trial results Table 5: Plant biomass as measured by plant cuts from the 2018 wheat crop.

# Treatment 1
Shoot dry weight (g/m2)
1 Control 613
2 DAFWA 350mm 633
3 DAFWA 350mm + Slotting 537
4 DAFWA 550mm 717

Shoot dry weight g/m2


Loading

Trial results Table 6: Economic return of the treatments for the 2016 season.

# Treatment 1
Treatment Cost ($/ha) Return on investment compared to control ($/ha) Net 1-year benefit ($/ha)
1 Control 0 0 0
2 Rip 350mm 40 54 68
3 Rip 350mm + Slotting 45 108 123
4 Rip 550mm 55 50 68
5 Heliripper_600mm 70 -108 -85
6 Offset Disk_150mm 15 93 98
7 Scarifier_250mm 15 64 69

Net 1-year benefit $/ha


Loading

Return on investment compared to control $/ha


Loading

Treatment Cost $/ha


Loading
Observed trial site soil information
Trial site soil testing
Site Depth Type pH EC P K N A OC CAT
Muradup, WA 0 - 10cm 5.50
Muradup, WA 10 - 20cm 4.80
Muradup, WA 20 - 30cm 4.90
Muradup, WA 30 - 40cm 5.30
Muradup, WA 40 - 50cm 5.60
Soil conditions
Trial site Soil texture
Muradup, WA Not specified
Derived trial site soil information
Australian Soil Classification Source: ASRIS
Trial site Soil order
Muradup, WA Chromosol
Soil Moisture Source: BOM/ANU
Average amount of water stored in the soil profile during the year, estimated by the OzWALD model-data fusion system.
Year Muradup WA
2018 423.7mm
2017 405.5mm
2016 437.7mm
2015 369.4mm
2014 420.7mm
2013 446.2mm
2012 444.3mm
2011 453.3mm
2010 396.8mm
2009 447.0mm
2008 437.2mm
2007 423.8mm
2006 399.0mm
2005 442.1mm
2004 431.8mm
2003 389.5mm
2002 304.5mm
2001 309.4mm
2000 437.1mm
National soil grid Source: CSIRO/TERN
NOTE: National Soil Grid data is aggregated information for background information on the wider area
Actual soil values can vary significantly in a small area and the trial soil tests are the most relevant data where available

Soil properties

Loading

Climate

Derived climate information

No observed climate data available for this trial.
Derived climate data is determined from trial site location and national weather sources.

Muradup WA

Loading
Loading
Loading

Some data on this site is sourced from the Bureau of Meteorology

SILO weather estimates sourced from https://www.longpaddock.qld.gov.au/silo/
Jeffrey, S.J., Carter, J.O., Moodie, K.B. and Beswick, A.R. (2001). Using spatial interpolation to construct a comprehensive archive of Australian climate data , Environmental Modelling and Software, Vol 16/4, pp 309-330. DOI: 10.1016/S1364-8152(01)00008-1.

Trial report and links

Project Final Report

2017 trial report

2017 trial report

Event Date Type Effect
Uneven N Application

Uneven N Application

July 2018 Pests 10%


Trial last modified: 14-12-2022 15:05pm AEST
